YAMATO AZF8611SD-C5DA 5X5MM ZIPPER FOOT OVERLOCK HEAD ONLY
Part No
AZF8611SDC5DA
Yamato AZF-8611SD-C5DA 2 Needle 5 Thread "Speed & Dry" Safety Stitch Machine with Top Feeder, for Attaching Zipper Tape
Pricing and Availability on Request
Description / YAMATO AZF8611SD-C5DA 5X5MM ZIPPER FOOT OVERLOCK HEAD ONLY
Yamato AZF-8611SD-C5DA
2 Needle 5 Thread "Speed & Dry" Safety Stitch Machine with Top Feeder, for Attaching Zipper Tape
With the Top Feeder to prevent plyshifts and the Zipper Tape Guide for attaching zipper tapes on heavy weight material.
The 3 in 1 Overlock & Safety Stitch Machines Series with Top and Bottom Feeders with the Perfect Path to Feed Fabric Securely that Offers High Speed, Stain Free Dry Finish and Higher Durability.
- Yamato AZF8000SD-8 & AZF8500SD-8 series realize high productivity by high speed operation, high quality garment by stain-free dry finish and long lifetime machines, thanks to Yamato's signature "Speed + Dry" Technology (a.k.a. SD Technology).
- Yamato AZF8000SD-8 & AZF8500SD-8 series are the 3 in 1 overlock and safety stitch machine series that offers high speed, stain free dry finish and higher durability.
- Upper and lower feed dogs make the perfect path to feed the fabric securely. They eliminate damages on light or delicate fabrics, without plyshifts even on all fabrics hard to feed. Also, curved sewing operations can be easily done.
The 3 in 1 Overlock & Safety Stitch Machines that Offers High Speed, Stain Free Dry Finish and Higher Durability.
Yamato AZ7000SDR-8 & AZ7500SDR-8 series realize high productivity by high speed operation, high quality garment by stain-free dry finish and long lifetime machines, thanks to Yamato's signature "Speed + Dry" Technology (a.k.a. SD Technology).
Yamato AZ7000SDR-8 & AZ7500SDR-8 series are the 3 in 1 overlock and safety stitch machine series that offers high speed, stain free dry finish and higher durability.
Tachnical Specifications
| Model | Yamato AZF-8611SD-C5DA |
|---|---|
| Needle System | DOx5 |
| Number of Needles | 2 |
| Number of Threads | 5 |
| Needle distance (mm) | 5.0 |
| Over-edge seam width (mm) | 5 |
| Stitch length (mm) | 2.0 - 5.0 |
| Feed regulation | Push button |
| Differential ratio | 1:0.6 - 1:3 |
| Differential feed regulation | Lever with micro-adjuster |
| Top feed back & forth movement (mm) | 8 |
| Top feed up & down movement (mm) | 5.0 - 8.0 |
| Top feed lift (mm) | 8.0 - 8.5 |
| Pressor foot lift (mm) | 7 |
| Needle stroke (mm) | 27.1 |
| Machine speed (sti/min) | 6,000 |
| Applications | For Attaching Zipper Tape |
| Remarks | Safety Stitch, with Floating Pressor Foot |
More Information
| Part No | AZF8611SDC5DA |
|---|---|
| Weight (KG) | 32.000000 |
| Manufacturer | Yamato |
