JUKI LU-2810A-7-0BBS/JEUX0031-1000MM 39" TRIMMER COMPLETE M/CH M51N SC922 CP180 STAND

Part No LU2810A70BBSJEUX0031
JUKI LU2810A70BBS/JEUX0031-1000MM The Juki Series LU-2800/JEUX0031 machine is a long arm, direct-drive lockstitch with vertical axis hook
Pricing and Availability on Request
Contact Us for Quote

Description / JUKI LU-2810A-7-0BBS/JEUX0031-1000MM 39" TRIMMER COMPLETE M/CH M51N SC922 CP180 STAND

JUKI LU2810A70BBS/JEUX0031-1000MM

The Juki Series LU-2800/JEUX0031 machine is a long arm, direct-drive lockstitch with vertical axis hook

The LU-2800 Series long arm (JEUX0031) has been extended to add to the wide bed area, contributing to vastly improved workability. The machine arm has been doubled in length from 35cm to 1m making it perfect for sewing large objects usually to awkward to fit under a sewing machine head. The machine has a high-torque direct-drive motor which supports the sewing of heavy-weight materials. As a result, the sewing machine promises not only improved responsiveness and quick start-up, but also higher stop accuracy. The long arm model is also available with 1-needle as well as a 70cm arm length. Furthermore the adoption of a 2.7 fold capacity hook reduces the amount the bobbin needs to be changed and therefore increases productivity. This long arm model is only available from Juki Central Europe and is manufactured in the EU.


Technical Specification

Model name LU-2868ALD70BBS /JEUX0031
Max. sewing speed 3,000sti/min
Max. stitch length 9mm
Needle 135x17 (Nm160) Nm125~Nm180
Lift of the presser foot Auto: 20mm, By Hand: 10mm
Thread #30~#5, B46~B138, Nm=60/3~20/3
Amount Of The Alternating Vertical Movement 1~9mm

More Information

Part No LU2810A70BBSJEUX0031
Weight (KG) 234.000000
Manufacturer Juki
