BROTHER DA-927A-3-264 2N 6.4MM MEDIUM WEIGHT F.O.A HEAD
Part No
BRODA92703264
Brother DA-927A-3-264
Twin Needle Feed Off the Arm Double Chain Stitcher
Clean Sewing with Minimum Lubrication System
A New Knife with Highly Safe Shape
Beautiful Sewing Finishes with New Presser Mechanism
Minimum lubrication system can be realizing clean sewing
Pricing and Availability on Request
Description / BROTHER DA-927A-3-264 2N 6.4MM MEDIUM WEIGHT F.O.A HEAD
Brother DA-927A-3-264
Twin Needle Feed Off the Arm Double Chain Stitcher
- Clean Sewing with Minimum Lubrication System
- A New Knife with Highly Safe Shape
- Beautiful Sewing Finishes with New Presser Mechanism
Minimum lubrication system can be realizing clean sewing
Minimum lubrication system supplies limited oil only to the needle bar and the upper shaft realizing clean sewing for your valued products.
A new knife with highly safe shape
Sewing work can be done safely with a new knife with highly safe shape.
Technical Specifications
| Model | Brother DA-927A-3-264 |
|---|---|
| Applications | Heavy materials |
| Lubrication type | Minimum lubrication |
| Max. sewing speed | 4,000sti/min*1 |
| Max. stitch length | 3.8mm |
| Height of presser foot | 10mm |
| Needle bar stroke | 30mm |
| Needle | TVX64NY 16 |
| Needle gauge | 2-needles '1/4 |
| Height of feed dog | 1.0mm |
| Weight | 49kg |
| Size | 465mm x 500mm x 340mm |
| Outer perimeter of cylinder | 171mm |
| Presser foot presser | 39.2~78.4N (4~8kgf) |
More Information
| Part No | BRODA92703264 |
|---|---|
| Weight (KG) | 0.100000 |
| Manufacturer | Brother |
