24X1 SIZE 125 PACK OF 10 NEEDLES SCHMETZ DISCONTINUED
Part No
24X1X125
Schmetz 02:65 1 - 24X1, DHX1 - NM 125 / Size 20 - STANDARD (Normal round point) Packet of 10 Needles.
£10.79
Only 22 Left In Stock!
Description / 24X1 SIZE 125 PACK OF 10 NEEDLES SCHMETZ DISCONTINUED
Schmetz 02:65 1 - 24X1, DHX1 - NM 125 / Size 20 - STANDARD (Normal round point) Packet of 10 Needles.
STANDARD (Normal round point)
The normal round point is the standard point form and has a slim, conical shape. No point supplement "R" is mentioned in the system code.
Needle Specification
| Customary Needle Designations | 24X1, DHX1 |
|---|---|
| CANU | 02:65 1 |
| NM / Size | NM: 125 / Size: 20 |
| Point Style | STANDARD (Normal round point) |
| Type of Coating | Chrome |
| Shank-ø | 2 mm |
| Overall Length | 32.1 mm |
| Length to Eye | 28.2 mm |
| Shank Flattening | With shank flattening |
| Flattening° | 180° |
| Blade Shape | Straight |
| Number of grooves | 1 |
| Stitch Type | Lockstitch |
More Information
| Part No | 24X1X125 |
|---|---|
| Weight (KG) | 0.015000 |
| Manufacturer | Schmetz |
| Needle Size | NM 125 / Size 20 |
